Electric Portable Air Compressor | Elec50

Emission-free, efficient, reliable

Pressure 5 to 12 bar

Volume Flow 3,5 m³/min at 12 bar; 5,0m³/min up to 7 bar

Motor Power 30kW

Weight <750kg

Applications

Dismantling and breaking tools
Blow-out work
Drilling
Earth rockets
Paint spraying/spraying
Sand and dry ice blasting
Environmental or noise protection areas
Applications in urban areas or indoors, such as in tunnels, narrow excavations or buildings

CompAir's portable compressors have proven reliability and efficiency under the toughest conditions. The new Elec50 compressors combine these characteristics with the advantages of an emission-free, extremely quiet and economical electric drive: The Elec50 is ideal for use in environmentally or noise-sensitive areas, e.g. in tunnels, narrow excavations or inside buildings. The compressor can be connected to the public power supply wherever a power socket is available. Compared to a comparable diesel vehicle, the Elec50 offers potential savings of up to 46% in energy costs and up to 36% in maintenance and repair costs.

Features	Benefits
IP55 (IE-3) - IEC 60034-2-1 ECA qualification	Future-proof investment with state-of-the-art and economical technology
Highly efficient compressor elements from our own German production	Low power consumption, electrical energy
Mobile 5 programme: up to 5 years warranty on the package except the engine	Operational safety with a guarantee
Bolted individual panels; galvanised, electrostatically powder-coated cladding panels as standard	Economical and quick replacement in the event of damage. Best protection against corrosion
Hinged bonnet with two robust gas springs	Good accessibility for maintenance
Robust plastic protection	Protects control panel and traffic safety elements
Optional compressed air filtration	Technically oil-free in accordance with ZTV -ING Part 3 Paragraph 4
Volume flow control	Automatically adjusted to the air consumption
Oil filter is screwed onto the compressor block	Quick and easy filter change
Oil temperature control valve as standard	Reduces the freezing of connected tools at low temperatures; use at ambient temperatures of -10 to +45 °C
Electrical main switch inside the compressor housing	Protection against misuse
Central lifting eye	Easy to move and lift by crane or helicopter
FPM Flexible power management with 16A to 63A	Extended application options thanks to flow rate adjustment during pressure setting; compatible with 63A CEE sockets and with optional adapters for 16A or 32A CEE sockets
